Steering Angle Sensor Calibration
In the past decade or so, manufacturers have added a number of sensors to the vehicle’s steering system. One of these is the SAS, typically found in multiples inside a steering column. An integral part of the vehicle’s stability control system, it provides an accurate reading on the position of the wheels and rate of turn. It also works with the yaw, accelerometer and wheel speed sensors to measure the dynamics of the vehicle; what the vehicle is doing, what the driver wants the vehicle to do, and what corrections need to be made by the ABS hydraulic control unit to maintain control of the vehicle.
direction in which the vehicle is travelling, then the stability control system will kick in to help the driver maintain control of the vehicle. For example, if understeer occurs, it will automatically apply the rear brake on the inside of the vehicle to correct the problem.
Do Steering Sensors Fail?
Whilst SAS are designed to last the lifetime of a vehicle, just like other electronic components, they are subject to wear and tear. They can also be damaged when working on other parts of the vehicle such as the power steering wheel. So, it pays to be familiar with the common symptoms of a faulty sensor just in case. Common signs to look out for include
Warning light comes on: when the SAS fails, it will trigger a stability system related warning light on the dashboard, indicating that the system has been disabled and requires servicing. On most cars this will be the traction control light but could also be the check engine light.
Travel in the steering wheel: if a SAS is faulty or misaligned, it can send inaccurate information to the electronic control unit (ECU). This can cause the vehicle’s stability control system to provide incorrect steering adjustments, resulting in either a loose steering wheel, or the steering not responding in the way it should.
Why Do You Need to Perform a Steering Angle Sensor Reset?
Since vehicles equipped with ESC, Advanced Driver Assistance Systems (ADAS) such as Lane Keep Assist (LKA) and Autonomous Emergency Braking (AEB), and other safety features, rely on accurate from the SAS, it is now necessary to reset them after performing a wheel alignment or replacing a component that can alter the toe and thrust angle. This will ensure these systems know exactly how the vehicle is traveling down the road in order to both predict, and make, the necessary safety corrections. If the SAS is out of calibration, and the angle is too far off, then the vehicle’s stability system will not function correctly, and ultimately will be disabled.
How Do You Reset the Steering Angle Sensor?
Whilst the procedure to do this can differ significantly between manufacturers and models, there are several main methods of calibrating the SAS with the other sensors that make up these systems:
- Self-calibration: Some newer vehicles, can self-calibrate or auto calibrate by turning the steering wheel from lock to lock to centre and then cycling the key. Others will also have a set of commands that need to be performed for the calibration to initiate.
- Test drive: Newer vehicles with more advanced wheel speed sensors may automatically reset their own steering angle sensor the next time the vehicle is driven in a straight line for a set period. This is usually just a few seconds at motorway speed.
- Diagnostic scan tool reset: A scan tool reset may be required on some vehicles. Some alignment systems even have the SAS reset function built into it, eliminating the need for a separate diagnostic procedure after an alignment.
Most manufacturers recommend that steering angle sensor calibration is performed on the ground, versus a lift. When in doubt, always refer to the manufacturer’s service manual for the correct procedure.
Just remember, whatever the vehicle, and whichever procedure they specify, steering angle reset should now be part of your standard alignment,providing yet another value-added service for independent garages.
